1 Safety Considerations

Hazards may exist within this equipment because it

contains electrical and powerful moving components.

Only qualified service personnel should install or

service this equipment. Untrained personnel can

perform basic maintenance such as maintaining filters.

Observe precautions marked in literature and on labels

attached to the unit. Follow all safety codes.

2 General Specifications

These ceiling series are a successful solution to

ventilation and indoor air quality problems. Intended for

installation within a suspended ceiling space or

mechanical room, these ventilators provide 100%

outdoor air ventilation.This series consists of commercial

interior heat and energy recovery ventilators.

HRV 20LCi

This ventilator tranfers the heat from the exhaust

airstream to the supply airstream. The Heat Recovery

Ventilator (HRV) uses a flat plate heat exchanger which

may be more suited to some applications requiring

stringent cross contamination control.

ERV w20LCi

This ventilator provides energy recovery between

the exhaust and supply airstreams. The Energy

Recovery Ventilator (ERV) uses an enthalpy wheel for

total energy recovery providing superior efficiency in

hot and humid climates.

Both models are also effective in cold climates and

use various types of frost control or defrost to ensure

operation when outside temperatures are extremely

low.

See Appendix A for more detailed equipment data.

3 Installation

3.1 Check Equipment

Move the unit to its installation location and remove

packaging. See Appendix A for unit weight and

specifications.

Remove all internal packaging (ERV w20LCi only)

Remove access panels and remove all packaging

from the unit. Note that there is packaging for the wheel

support during shipping. Removal of all this packaging

is critical.

Inspection

Inspect the equipment, exterior and interior, for

damage. Ensure that there is no damage to the internal

components such as fans, motors, dampers, flat plate

heat exchangers or enthalpy wheel, insulation, drains

(if applicable) and structures. File a claim with the shipping

company if the unit is damaged.

System Requirements

Consult National Electrical Code and local building

codes for special installation requirements. Note

additional requirements in Appendix A and in the Start-Up

Section (page 7). Also, see Appendix C for more

electrical data information.

The unit should be installed to allow easy access

for maintenance. Appendix D and E show minimum

clearance requirements between front access and any

obstruction to allow for removal of components (fans,

filters, flat plate heat exchangers or enthalpy wheel).

The front of the unit is defined in relation to the inlet

ports and outlet ports on the unit. Port location and

overall dimensions shown in Appendix D and E.

In cold climates with -5°F (-20°C) design, the unit

must be mounted in a dry area (not exceeding 30% RH)

to avoid water condensation on the cabinet during winter

operation. Alternatively, accommodation must be made

for condensation on the cabinet exterior. Heat recovery

model (20LCi) should be mounted in a heated space to

prevent drain lines from freezing. Do not mount units in

an area where exposure to hot chimneys, electrical

panels or other hazards will occur.

A mounting location close to an exterior partition will

minimize the length of insulated ductwork required.

Appendix B illustrates ductwork through exterior partitions.

These should be separated by a minimum of 8 feet

(2438mm) to avoid outside cross contamination.

WARNING

Disconnect main power switches to unit before

performing service or maintenance. Electric shock

can cause personal injury or death.
